型号名称:
型号 | 名称 |
KFV | 铜芯 F46 绝缘 105 ℃ 阻燃氯乙烯护套控制电缆 |
KFF | F46 绝缘 F46 护套高温控制电缆 |
KFPF | F46 绝缘 F46 护套屏蔽高温控制电缆 |
适用范围:
适用于石油,化工,发电,冶金等企业,在高温、低温和有酸、碱、油及腐蚀性气体等恶劣环境中用作电器仪表
和自动化控制系统中的信号传输线。
KFV结构数据
芯数×标称截面 (mm2) | 导体线芯 | 电缆最大外径 (mm) | 计算重量(kg/km) | |
种类 | 根数/直径(mm) | |||
2×0.5 | A | 1/0.80 | 6.2 | 43 |
B | 7/0.30 | 6.4 | 45 | |
R | 16/0.20 | 6.4 | 46 | |
2×0.75 | A | 1/0.97 | 6.6 | 50 |
B | 7/0.37 | 6.8 | 54 | |
R | 24/0.20 | 6.9 | 54 | |
2×1.0 | A | 1/1.13 | 6.8 | 56 |
B | 7/0.43 | 7.3 | 60 | |
R | 32/0.20 | 7.3 | 62 | |
2×1.5 | A | 1/1.38 | 7.6 | 73 |
B | 7/0.52 | 8.5 | 78 | |
R | 30/0.25 | 8.6 | 79 | |
2×2.5 | A | 1/1.78 | 8.8 | 105 |
B | 7/0.68 | 9.6 | 111 | |
R | 49/0.25 | 9.6 | 113 | |
3×0.5 | A | 1/0.80 | 6.4 | 53 |
B | 7/0.30 | 6.7 | 56 | |
R | 16/0.20 | 6.8 | 56 | |
3×0.75 | A | 1/0.97 | 6.8 | 62 |
B | 7/0.37 | 7.2 | 67 | |
R | 24/0.20 | 7.3 | 68 | |
3×1.0 | A | 1/1.13 | 7.3 | 72 |
B | 7/0.43 | 7.6 | 77 | |
R | 32/0.20 | 7.6 | 80 | |
3×1.5 | A | 1/1.38 | 7.9 | 95 |
B | 7/0.52 | 8.9 | 101 | |
R | 30/0.25 | 9.0 | 103 | |
3×2.5 | A | 1/1.78 | 9.4 | 138 |
B | 7/0.68 | 10.1 | 149 | |
R | 49/0.25 | 10.1 | 147 | |
4×0.5 | A | 1/0.80 | 6.8 | 63 |
B | 7/0.30 | 7.2 | 66 | |
R | 16/0.20 | 7.3 | 67 | |
4×0.75 | A | 1/0.97 | 7.6 | 77 |
B | 7/0.37 | 7.7 | 81 | |
R | 24/0.20 | 7.8 | 82 | |
4×1.0 | A | 1/1.13 | 7.8 | 88 |
B | 7/0.43 | 8.1 | 95 | |
R | 32/0.20 | 8.2 | 97 | |
4×1.5 | A | 1/1.38 | 8.6 | 118 |
B | 7/0.52 | 9.7 | 125 | |
R | 30/0.25 | 9.8 | 127 | |
4×2.5 | A | 1/1.78 | 10.2 | 174 |
B | 7/0.68 | 11.0 | 187 | |
R | 49/0.25 | 11.0 | 184 | |
5×0.5 | A | 1/0.80 | 7.3 | T6 |
B | 7/0.30 | 7.7 | 80 | |
R | 16/0.20 | 7.8 | 81 | |
5×0.75 | A | 1/0.97 | 7.9 | 91 |
B | 7/0.37 | 8.3 | 97 | |
R | 24/0.20 | 8.4 | 99 | |
5×1.0 | A | 1/1.13 | 8.4 | 107 |
B | 7/0.43 | 8.8 | 114 | |
R | 32/0.20 | 8.8 | 117 | |
5×1.5 | A | 1/1.38 | 9.2 | 145 |
B | 7/0.52 | 10.5 | 154 | |
R | 30/0.25 | 10.5 | 156 | |
5×2.5 | A | 1/1.78 | 11.1 | 217 |
B | 7/0.68 | 12.0 | 232 | |
R | 49/0.25 | 12.0 | 230 | |
6×0.5 | A | 1/0.80 | 7.9 | 89 |
B | 7/0.30 | 8.3 | 93 | |
R | 16/0.20 | 8.3 | 95 | |
6×0.75 | A | 1/0.97 | 8.5 | 106 |
B | 7/0.37 | 8.9 | 114 | |
R | 24/0.20 | 9.0 | 116 | |
6×1.0 | A | 1/1.13 | 9.0 | 125 |
B | 7/0.43 | 9.6 | 133 | |
R | 32/0.20 | 9.6 | 139 | |
6×1.5 | A | 1/1.38 | 10.0 | 170 |
B | 7/0.52 | 11.3 | 180 | |
R | 30/0.25 | 11.5 | 183 | |
6×2.5 | A | 1/1.78 | 12.0 | 257 |
B | 7/0.68 | 13.0 | 277 | |
R | 49/0.25 | 13.0 | 273 | |
7×0.5 | A | 1/0.80 | 7.9 | 92 |
B | 7/0.30 | 8.3 | 96 | |
R | 16/0.20 | 8.3 | 96 | |
7×0.75 | A | 1/0.97 | 8.5 | 113 |
B | 7/0.37 | 8.9 | 121 | |
R | 24/0.20 | 9.0 | 123 | |
7×1.0 | A | 1/1.13 | 9.0 | 134 |
B | 7/0.43 | 9.6 | 143 | |
R | 32/0.20 | 9.6 | 148 | |
7×1.5 | A | 1/1.38 | 10.0 | 183 |
B | 7/0.52 | 11.3 | 194 | |
R | 30/0.25 | 11.5 | 197 | |
7×2.5 | A | 1/1.78 | 12.0 | 279 |
B | 7/0.68 | 13.0 | 301 | |
R | 49/0.25 | 13.0 | 296 | |
8×0.5 | A | 1/0.80 | 8.4 | 103 |
B | 7/0.30 | 8.7 | 108 | |
R | 16/0.20 | 8.9 | 109 | |
8×0.75 | A | 1/0.97 | 9.0 | 125 |
B | 7/0.37 | 9.5 | 135 | |
R | 24/0.20 | 9.7 | 138 | |
8×1.0 | A | 1/1.13 | 9.7 | 150 |
B | 7/0.43 | 10.2 | 161 | |
R | 32/0.20 | 10.2 | 166 | |
8×1.5 | A | 1/1.38 | 10.8 | 206 |
B | 7/0.52 | 12.2 | 218 | |
R | 30/0.25 | 12.4 | 222 | |
8×2.5 | A | 1/1.78 | 12.9 | 314 |
B | 7/0.68 | 14.6 | 359 | |
R | 49/0.25 | 14.6 | 353 | |
9×0.5 | A | 1/0.80 | 9.0 | 115 |
B | 7/0.30 | 9.5 | 120 | |
R | 16/0.20 | 9.7 | 122 | |
9×0.75 | A | 1/0.97 | 9.9 | 140 |
B | 7/0.37 | 10.2 | 151 | |
R | 24/0.20 | 10.5 | 154 | |
9×1.0 | A | 1/1.13 | 10.5 | 169 |
B | 7/0.43 | 11.1 | 180 | |
R | 32/0.20 | 11.1 | 185 | |
9×1.5 | A | 1/1.38 | 11.7 | 232 |
B | 7/0.52 | 12.3 | 245 | |
R | 30/0.25 | 12.6 | 249 | |
9×2.5 | A | 1/1.78 | 14.9 | 376 |
B | 7/0.68 | 16.1 | 400 | |
R | 49/0.25 | 16.1 | 394 | |
10×0.5 | A | 1/0.80 | 9.6 | 126 |
B | 7/0.30 | 10.0 | 130 | |
R | 16/0.20 | 10.2 | 133 | |
10×0.75 | A | 1/0.97 | 10.9 | 153 |
B | 7/0.37 | 11.1 | 166 | |
R | 24/0.20 | 11.1 | 169 | |
10×1.0 | A | 1/1.13 | 11.1 | 185 |
B | 7/0.43 | 11.3 | 198 | |
R | 32/0.20 | 11.3 | 205 | |
10×1.5 | A | 1/1.38 | 12.4 | 254 |
B | 7/0.52 | 12.9 | 270 | |
R | 30/0.25 | 15.0 | 272 | |
10×2.5 | A | 1/1.78 | 15.6 | 411 |
B | 7/0.68 | 17.1 | 443 | |
R | 49/0.25 | 17.1 | 436 | |
12×0.5 | A | 1/0.80 | 9.8 | 144 |
B | 7/0.30 | 10.3 | 150 | |
R | 16/0.20 | 10.6 | 153 | |
12×0.75 | A | 1/0.97 | 10.6 | 177 |
B | 7/0.37 | 11.2 | 187 | |
R | 24/0.20 | 11.4 | 194 | |
12×1.0 | A | 1/1.13 | 11.4 | 213 |
B | 7/0.43 | 12.2 | 235 | |
R | 32/0.20 | 12.2 | 238 | |
12×1.5 | A | 1/1.38 | 12.8 | 294 |
B | 7/0.52 | 15.3 | 330 | |
R | 30/0.25 | 15.8 | 340 | |
12×2.5 | A | 1/1.78 | 16.2 | 477 |
B | 7/0.68 | 17.6 | 516 | |
R | 49/0.25 | 17.6 | 507 | |
14×0.5 | A | 1/0.80 | 10.2 | 162 |
B | 7/0.30 | 10.8 | 168 | |
R | 16/0.20 | 11.0 | 173 | |
14×0.75 | A | 1/0.97 | 11.1 | 201 |
B | 7/0.37 | 11.8 | 216 | |
R | 24/0.20 | 12.0 | 221 | |
14×1.0 | A | 1/1.13 | 12.0 | 242 |
B | 7/0.43 | 12.7 | 259 | |
R | 32/0.20 | 12.7 | 268 | |
14×1.5 | A | 1/1.38 | 13.4 | 335 |
B | 7/0.52 | 16.1 | 378 | |
R | 30/0.25 | 16.4 | 382 | |
14×2.5 | A | 1/1.78 | 17.1 | 549 |
B | 7/0.68 | 18.5 | 586 | |
R | 49/0.25 | 13.5 | 576 | |
16×0.5 | A | 1/0.80 | 10.8 | 182 |
B | 7/0.30 | 11.2 | 191 | |
R | 16/0.20 | 11.6 | 195 | |
16×0.75 | A | 1/0.97 | 11.7 | 226 |
B | 7/0.37 | 12.3 | 246 | |
R | 24/0.20 | 12.5 | 249 | |
16×1.0 | A | 1/1.13 | 12.5 | 275 |
B | 7/0.43 | 13.3 | 294 | |
R | 32/0.20 | 13.3 | 303 | |
16×1.5 | A | 1/1.38 | 14.7 | 407 |
B | 7/0.52 | 16.8 | 428 | |
R | 30/0.25 | 17.1 | 437 | |
16×2.5 | A | 1/1.78 | 17.9 | 621 |
B | 7/0.68 | 19.6 | 668 | |
R | 49/0.25 | 19.6 | 656 | |
18×0.5 | A | 1/0.80 | 11.3 | 203 |
B | 7/0.30 | 119 | 213 | |
R | 16/0.20 | 12.1 | 212 | |
18×0.75 | A | 1/0.97 | 12.3 | 252 |
B | 7/0.37 | 13.0 | 273 | |
R | 24/0.20 | 13.2 | 278 | |
18×1.0 | A | 1/1.13 | 13.2 | 307 |
B | 7/0.43 | 14.7 | 346 | |
R | 32/0.20 | 14.7 | 358 | |
18×1.5 | A | 1/1.38 | 15.5 | 449 |
B | 7/0.52 | 17.7 | 476 | |
R | 30/0.25 | 18.0 | 487 | |
18×2.5 | A | 1/1.78 | 18.8 | 693 |
B | 7/0.68 | 20.9 | 776 | |
R | 49/0.25 | 20.9 | 753 | |
19×05 | A | 1/0.80 | 11.3 | 207 |
B | 7/0.30 | 11.9 | 217 | |
R | 16/0.20 | 12.0 | 220 | |
19×0.75 | A | 1/0.97 | 12.3 | 259 |
B | 7/0.37 | 13.0 | 280 | |
R | 24/0.20 | 13.2 | 285 | |
19×1.0 | A | 1/1.13 | 13.2 | 315 |
B | 7/0.43 | 14.7 | 357 | |
R | 32/0.20 | 14.7 | 369 | |
19×1.5 | A | 1/1.38 | 15.5 | 461 |
B | 7/0.52 | 17.7 | 489 | |
R | 30/0.25 | 13.0 | 501 | |
19×2.5 | A | 1/1.78 | 18.8 | 716 |
B | 7/0.68 | 20.9 | 790 | |
R | 49/0.25 | 20.9 | 777 |
KFF、KFPF结构数据
芯数×标称截面 (mm2) | 导体线芯 | 电缆最大外径(mm) | 计算重量(kg/km) | |||
种类 | 根数/直径(mm) | KFF | KFPF | KFF | KFPF | |
2×0.2 | A | 1/0.50 | 4.2 | 4.9 | 22.01 | 38.90 |
B | 7/0.20 | 4.5 | 5.2 | 24.61 | 41.50 | |
2×0.35 | A | 1/0.67 | 4.6 | 5.3 | 27.54 | 42.80 |
B | 7/0.26 | 4.8 | 5.6 | 29.79 | 48.20 | |
2×0.5 | A | 1/0.80 | 4.8 | 5.6 | 31.89 | 51.74 |
B | 7/0.30 | 5.0 | 5.8 | 33.58 | 53.45 | |
R | 16/0.20 | 5.2 | 6.0 | 35.41 | 54.36 | |
2×0.75 | A | 1/0.97 | 5.2 | 6.0 | 44.85 | 63.69 |
B | 7/0.37 | 5.8 | 6.8 | 45.04 | 71.45 | |
R | 24/0.20 | 6.1 | 7.2 | 48.40 | 76.27 | |
2×1.0 | A | 1/1.13 | 5.8 | 6.6 | 49.03 | 81.78 |
B | 7/0.43 | 6.2 | 7.2 | 53.53 | 81.92 | |
R | 32/0.20 | 6.4 | 7.4 | 55.98 | 85.08 | |
2×1.5 | A | 1/1.38 | 6.9 | 7.6 | 72.13 | 103.27 |
B | 7/0.52 | 7.3 | 8.0 | 76.58 | 101.90 | |
R | 30/0.25 | 7.4 | 8.4 | 78.35 | 113.24 | |
2×2.5 | A | 1/1.78 | 7.9 | 8.9 | 100.75 | 139.36 |
B | 7/0.68 | 8.5 | 9.5 | 109.59 | 151.30 | |
R | 49/0.25 | 8.8 | 9.8 | 102.T7 | 155.92 | |
2×4.0 | B | 7/0.85 | 9.9 | 11.0 | 170.16 | 224.23 |
R | 56/0.30 | 10.3 | 11.2 | 183.87 | 232.42 | |
2×6.0 | B | 7/1.04 | 11.4 | 12.5 | 237.59 | 299.90 |
R | 84/0.30 | 11.7 | 12.8 | 240.06 | 313.12 | |
3×0.2 | A | 1/0.50 | 4.4 | 5.2 | 27.27 | 46.92 |
B | 7/0.20 | 4.7 | 5.5 | 30.54 | 45.36 | |
3×0.35 | A | 1/0.67 | 4.8 | 5.6 | 34.74 | 57.30 |
B | 7/0.26 | 5.0 | 5.9 | 37.68 | 52.23 | |
3×0.5 | A | 1/0.80 | 5.1 | 5.9 | 41.24 | 62.72 |
B | 7/0.30 | 5.3 | 6.1 | 43.39 | 64.37 | |
R | 16/0.20 | 5.5 | 6.3 | 44.49 | 65.82 | |
3×0.75 | A | 1/0.97 | 5.5 | 6.2 | 51.16 | 76.52 |
B | 7/0.37 | 6.1 | 7.1 | 58.71 | 86.58 | |
R | 24/0.20 | 6.5 | 7.5 | 63.55 | 93.35 | |
3×1.0 | A | 1/1.13 | 6.1 | 7.1 | 64.68 | 99.28 |
B | 7/0.43 | 6.5 | 7.5 | 70.61 | 100.41 | |
R | 32/0.20 | 7.1 | 7.8 | 80.66 | 105.20 | |
3×1.5 | A | 1/1.38 | 7.2 | 7.8 | 94.66 | 125.48 |
B | 7/0.52 | 7.7 | 3.6 | 100.85 | 137.08 | |
R | 30/0.25 | 7.8 | 8.7 | 103.23 | 139.84 | |
3×2.5 | A | 1/1.78 | 8.3 | 9.3 | 135.56 | 176.17 |
B | 7/0.68 | 9.1 | 10.2 | 149.15 | 198.62 | |
R | 49/0.25 | 9.4 | 10.5 | 151.44 | 204.18 | |
3×4.0 | B | 7/0.85 | 10.7 | 11.6 | 214.22 | 267.82 |
R | 56/0.30 | 10.9 | 11.8 | 222.43 | 274.03 | |
3×6.0 | B | 7/1.04 | 12.1 | 13.2 | 309.33 | 375.87 |
R | 84/0.30 | 12.7 | 13.6 | 335.53 | 393.86 | |
4×0.2 | A | 1/0.50 | 4.8 | 5.6 | 33.34 | 50.96 |
B | 7/0.20 | 5.1 | 5.9 | 37.31 | 55.86 | |
4×0.35 | A | 1/0.67 | 5.2 | 6.0 | 42.75 | 63.40 |
B | 7/0.26 | 5.5 | 6.3 | 46.82 | 66.96 | |
4×0.5 | A | 1/0.80 | 5.5 | 6.3 | 51.01 | 77.23 |
B | 7/0.30 | 5.8 | 6.8 | 54.51 | 80.92 | |
R | 16/0.20 | 6.0 | 7.0 | 57.38 | 87.75 | |
4×0.75 | A | 1/0.97 | 6.0 | 7.0 | 64.65 | 93.62 |
B | 7/0.37 | 6.9 | 7.6 | 79.75 | 103.53 | |
R | 24/0.20 | 7.3 | 8.0 | 86.05 | 111.36 | |
4×1.0 | A | 1/1.13 | 6.9 | 7.6 | 87.72 | 118.82 |
B | 7/0.43 | 7.4 | 8.4 | 95.97 | 133.29 | |
R | 32/0.20 | 7.7 | 8.6 | 100.32 | 136.44 | |
4×1.5 | A | 1/1.38 | 7.9 | 8.8 | 119.36 | 155.55 |
B | 7/0.52 | 8.4 | 9.4 | 126.70 | 167.90 | |
R | 30/0.25 | 8.6 | 9.6 | 130.20 | 172.45 | |
4×2.5 | A | 1/1.78 | 9.2 | 10.3 | 173.88 | 223.93 |
B | 7/0.68 | 10.2 | 11.1 | 196.12 | 244.18 | |
R | 49/0.25 | 10.5 | 11.4 | 200.88 | 250.45 | |
4×4.0 | B | 7/0.85 | 11.7 | 12.8 | 272.64 | 336.69 |
R | 84/0.30 | 13.9 | 14.8 | 419.98 | 486.39 | |
5×0.2 | A | 1/0.50 | 5.1 | 5.9 | 39.02 | 63.15 |
B | 7/0.20 | 5.5 | 6.3 | 44.06 | 64.19 | |
5×0.35 | A | 1/0.67 | 5.6 | 6.7 | 50.76 | 81.64 |
B | 7/0.26 | 6.0 | 7.0 | 56.51 | 83.89 | |
5×0.5 | A | 1/0.80 | 6.0 | 7.0 | 61.75 | 95.71 |
B | 7/0.30 | 6.3 | 7.3 | 65.72 | 98.56 | |
R | 16/0.20 | 6.9 | 7.6 | 75.50 | 99.30 | |
5×0.75 | A | 1/0.97 | 6.9 | 7.6 | 84.60 | 115.74 |
B | 7/0.37 | 7.5 | 8.4 | 95.33 | 130.45 | |
R | 24/0.20 | 8.0 | 8.9 | 103.22 | 142.29 | |
5×1.0 | A | 1/1.13 | 7.5 | 8.4 | 105.28 | 140.40 |
B | 7/0.43 | 8.0 | 9.0 | 114.59 | 152.58 | |
R | 32/0.20 | 8.4 | 9.4 | 120.49 | 161.69 | |
5×1.5 | A | 1/1.38 | 8.6 | 9.6 | 144.07 | 186.32 |
B | 7/0.52 | 9.2 | 10.3 | 154.06 | 204.11 | |
R | 30/0.25 | 9.4 | 10.6 | 158.20 | 207.40 | |
5×2.5 | A | 1/1.78 | 10.2 | 11.1 | 223.13 | 272.60 |
B | 7/0.68 | 11.1 | 12.0 | 244.19 | 296.80 | |
R | 49/0.25 | 11.4 | 12.5 | 249.95 | 312.27 | |
5×4.0 | B | 7/0.85 | 13.0 | 13.9 | 350.05 | 411.88 |
R | 56/0.30 | 13.3 | 14.2 | 364.63 | 427.71 | |
5×6.0 | B | 7/1.04 | 14.8 | 15.7 | 479.98 | 550.98 |
R | 84/0.30 | 15.2 | 16.2 | 502.45 | 575.45 | |
7×0.2 | A | 1/0.50 | 5.5 | 6.3 | 49.51 | 75.75 |
B | 7/0.20 | 6.0 | 7.0 | 56.88 | 84.25 | |
7×0.35 | A | 1/0.67 | 6.1 | 7.1 | 66.10 | 100.10 |
B | 7/0.26 | 6.5 | 7.5 | 72.80 | 102.60 | |
7×0.5 | A | 1/0.80 | 6.5 | 7.5 | 80.12 | 117.15 |
B | 7/0.30 | 7.1 | 7.8 | 91.20 | 125.75 | |
R | 16/0.20 | 7.4 | 8.3 | 96.32 | 130.88 | |
7×0.75 | A | 1/0.97 | 7.4 | 8.3 | 109.02 | 147.22 |
B | 7/0.37 | 8.1 | 9.1 | 123.30 | 162.93 | |
R | 24/0.20 | 8.6 | 9.6 | 133.25 | 175.50 | |
7×1.0 | A | 1/1.13 | 8.1 | 9.2 | 137.23 | 176.86 |
B | 7/0.43 | 8.7 | 9.7 | 150.23 | 193.01 | |
R | 32/0.20 | 9.2 | 10.3 | 158.65 | 208.70 | |
7×1.5 | A | 1/1.38 | 9.4 | 10.4 | 191.25 | 241.90 |
B | 7/0.52 | 10.2 | 11.1 | 209.30 | 257.37 | |
R | 30/0.25 | 10.5 | 11.3 | 215.45 | 265.52 | |
7×2.5 | A | 1/1.78 | 11.1 | 12.0 | 288.28 | 340.89 |
B | 7/0.68 | 12.1 | 13.2 | 314.15 | 380.50 | |
R | 49/0.25 | 12.7 | 13.6 | 330.02 | 390.33 | |
7×4.0 | B | 7/0.85 | 14.1 | 15.0 | 452.25 | 519.68 |
R | 56/0.30 | 14.5 | 15.4 | 471.26 | 540.71 | |
7×6.0 | B | 7/1.04 | 16.2 | 17.1 | 625.47 | 703.54 |
R | 84/0.30 | 16.7 | 17.8 | 654.70 | 747.34 | |
R | 84/0.30 | 16.7 | 17.8 | 654.70 | 747.34 | |
8×0.2 | A | 1/0.50 | 6.0 | 7.0 | 56.55 | 90.51 |
B | 7/0.20 | 6.4 | 7.3 | 63.70 | 93.00 | |
8×0.35 | A | 1/0.67 | 6.9 | 7.6 | 81.13 | 112.90 |
B | 7/0.26 | 7.3 | 8.0 | 96.27 | 114.25 | |
8×0.5 | A | 1/0.80 | 7.3 | 8.0 | 97.30 | 130.47 |
B | 7/0.30 | 7.5 | 8.5 | 102.42 | 138.05 | |
R | 16/0.20 | 7.9 | 8.9 | 109.05 | 146.60 | |
8×0.75 | A | 1/0.97 | 7.9 | 8.9 | 122.57 | 161.15 |
B | 7/0.37 | 8.7 | 9.7 | 138.89 | 181.66 | |
R | 24/0.20 | 9.4 | 10.5 | 151.94 | 203.14 | |
8×1.0 | A | 1/1.13 | 8.7 | 9.7 | 154.81 | 197.58 |
B | 7/0.43 | 9.5 | 10.6 | 171.29 | 223.07 | |
R | 32/0.20 | 9.9 | 11.0 | 178.96 | 233.02 | |
8×1.5 | A | 1/1.38 | 11.0 | 11.2 | 228.92 | 271.95 |
B | 7/0.52 | 11.3 | 11.9 | 236.40 | 288.50 | |
R | 30/0.25 | 11.5 | 12.3 | 243.10 | 304.85 | |
8×2.5 | A | 1/1.78 | 12.0 | 13.1 | 326.46 | 392.21 |
B | 7/0.68 | 13.3 | 14.2 | 364.50 | 427.88 | |
R | 49/0.25 | 13.7 | 14.6 | 373.03 | 438.43 | |
8×4.0 | B | 7/0.85 | 15.3 | 16.2 | 512.73 | 586.25 |
R | 56/0.30 | 15.7 | 16.2 | 534.06 | 609.60 | |
8×6.0 | B | 7/1.04 | 17.1 | 18.6 | 721.09 | 806.38 |
R | 84/0.30 | 18.3 | 19.3 | 755.33 | 846.86 | |
10×0.2 | A | 1/0.50 | 7.2 | 7.9 | 76.09 | 100.72 |
B | 7/0.20 | 7.7 | 8.6 | 85.60 | 121.65 | |
10×0.35 | A | 1/0.67 | 7.9 | 8.9 | 99.18 | 137.77 |
B | 7/0.26 | 8.4 | 9.4 | 108.95 | 150.15 | |
10×0.5 | A | 1/0.80 | 8.4 | 9.4 | 119.42 | 160.62 |
B | 7/0.30 | 8.9 | 9.8 | 127.38 | 169.23 | |
R | 16/0.20 | 9.3 | 10.4 | 135.68 | 185.22 | |
10×0.75 | A | 1/0.97 | 9.3 | 10.4 | 152.77 | 203.39 |
B | 7/0.37 | 10.5 | 11.3 | 180.15 | 229.22 | |
R | 24/0.20 | 11.1 | 12.0 | 194.27 | 246.88 | |
10×1.0 | A | 1/1.13 | 10.5 | 11.3 | 200.05 | 249.63 |
B | 7/0.43 | 11.3 | 12.4 | 218.98 | 280.73 | |
R | 32/0.20 | 11.7 | 12.8 | 228.32 | 292.38 | |
10×1.5 | A | 1/1.38 | 12.1 | 13.2 | 275.79 | 342.15 |
B | 7/0.52 | 13.1 | 14.0 | 296.70 | 364.36 | |
R | 30/0.25 | 13.4 | 14.3 | 319.16 | 373.03 | |
10×2.5 | A | 1/1.78 | 14.3 | 15.2 | 414.11 | 482.55 |
B | 7/0.68 | 15.6 | 16.2 | 451.15 | 526.20 | |
R | 49/0.25 | 16.1 | 17.0 | 461.87 | 539.40 | |
10×4.0 | B | 7/0.85 | 18.2 | 19.2 | 647.88 | 738.90 |
R | 56/0.30 | 18.7 | 19.7 | 674.88 | 768.53 | |
10×6.0 | B | 7/1.04 | 20.0 | 21.9 | 898.63 | 1000.30 |
R | 84/0.30 | 21.7 | 22.6 | 941.18 | 1046,40 | |
12×0.2 | A | 1/0.50 | 7.4 | 8.3 | 85.98 | 120.50 |
B | 7/0.20 | 7.9 | 8.9 | 96.83 | 135.40 | |
12×0.35 | A | 1/0.67 | 8.1 | 9.1 | 112.98 | 152.60 |
B | 7/0.26 | 8.8 | 9.7 | 126.12 | 167.65 | |
12×0.5 | A | 1/0.80 | 8.7 | 9.7 | 137.25 | 174.03 |
B | 7/0.30 | 9.2 | 10.36 | 146.17 | 196.22 | |
R | 16/0.20 | 9.6 | 10.7 | 155.35 | 206.72 | |
12×0.75 | A | 1/0.97 | 9.6 | 10.7 | 176.17 | 228.52 |
B | 7/0.37 | 10.7 | 11.7 | 206.75 | 257.87 | |
R | 24/0.20 | 11.5 | 12.6 | 223.60 | 286.50 | |
12×1.0 | A | 1/1.13 | 10.8 | 11.7 | 230.66 | 281.75 |
B | 7/0.43 | 11.7 | 12.8 | 253.02 | 317.08 | |
R | 32/0.20 | 12.1 | 13.2 | 263.73 | 330.09 | |
12×1.5 | A | 1/1.38 | 12.6 | 13.5 | 327.83 | 387.65 |
B | 7/0.52 | 13.5 | 14.4 | 348.00 | 412.40 | |
R | 30/0.25 | 13.8 | 14.7 | 357.40 | 423.40 | |
12×2.5 | A | 1/1.78 | 14.7 | 15.6 | 482.05 | 552.55 |
B | 7/0.68 | 16.1 | 17.0 | 525.45 | 603.02 | |
R | 49/0.25 | 16.6 | 17.7 | 537.55 | 629.42 | |
12×4.0 | B | 7/0.85 | 18.8 | 19.8 | 756.85 | 851.05 |
R | 56/0.30 | 19.4 | 20.3 | 791.75 | 885.34 | |
12×6.0 | B | 7/1.04 | 20.8 | 22.9 | 1054.60 | 1175.62 |
R | 84/0.30 | 22.4 | 23.5 | 1129.08 | 1228.35 | |
14×0.2 | A | 1/0.50 | 7.8 | 8.8 | 96.98 | 135.03 |
B | 7/0.20 | 8.3 | 9.3 | 109.71 | 149.32 | |
14×0.35 | A | 1/0.67 | 8.5 | 9.5 | 127.85 | 169.58 |
B | 7/0.26 | 9.2 | 10.5 | 150.48 | 192.52 | |
14×0.5 | A | 1/0.80 | 9.2 | 10.3 | 157.13 | 207.18 |
B | 7/0.30 | 9.6 | 10.7 | 165.49 | 217.84 | |
R | 16/0.20 | 10.2 | 11.1 | 181.28 | 229.33 | |
14×0.75 | A | 1/0.97 | 10.2 | 11.1 | 206.74 | 254.78 |
B | 7/0.37 | 11.3 | 12.4 | 234.64 | 296.38 | |
R | 24/0.20 | 11.8 | 12.9 | 252.44 | 317.08 | |
14×1.0 | A | 1/1.13 | 11.3 | 12.4 | 262.51 | 324.15 |
B | 7/0.43 | 12.4 | 13.3 | 295.78 | 354.57 | |
R | 32/0.20 | 12.9 | 13.8 | 309.02 | 370.16 | |
14×1.5 | A | 1/1.38 | 13.3 | 14.2 | 374.57 | 437.95 |
B | 7/0.52 | 14.2 | 15.1 | 397.10 | 465.02 | |
R | 30/0.25 | 14.5 | 15.4 | 407.68 | 477.12 | |
14×2.5 | A | 1/1.78 | 15.5 | 16.4 | 552.80 | 628.34 |
B | 7/0.68 | 16.9 | 18.0 | 601.80 | 695.39 | |
R | 49/0.25 | 17.7 | 18.6 | 627.90 | 713.00 | |
14×4.0 | B | 7/0.85 | 19.9 | 20.8 | 878.90 | 968.32 |
R | 56/0.30 | 20.4 | 21.3 | 908.65 | 1067.25 | |
14×6.0 | B | 7/1.04 | 23.0 | 23.8 | 1227.60 | 1339.00 |
R | 84/0.30 | 23.8 | 24.7 | 1251.10 | 1403.80 | |
16×0.2 | A | 1/0.50 | 8.2 | 9.2 | 107.96 | 140.11 |
B | 7/0.20 | 8.7 | 9.7 | 121.52 | 164.28 | |
16×0.35 | A | 1/0.67 | 9.1 | 10.2 | 144.72 | 194.10 |
B | 7/0.26 | 9.7 | 10.6 | 159.38 | 212.10 | |
16×0.5 | A | 1/0.80 | 9.7 | 10.6 | 176.12 | 229.05 |
B | 7/0.30 | 10.3 | 11.2 | 192.05 | 240.58 | |
R | 16/0.20 | 10.8 | 11.7 | 203.15 | 254.22 | |
16×0.75 | A | 1/0.97 | 10.8 | 11.7 | 232.21 | 283.30 |
B | 7/0.37 | 11.9 | 13.0 | 263.13 | 328.35 | |
R | 24/0.20 | 12.9 | 13.8 | 293.20 | 354.55 | |
16×1.0 | A | 1/1.13 | 11.9 | 13.0 | 294.98 | 360.19 |
B | 7/0.43 | 13.1 | 14.0 | 332.15 | 394.50 | |
R | 32/0.20 | 13.6 | 14.5 | 346.55 | 411.45 | |
16×1.5 | A | 1/1.38 | 14.0 | 14.9 | 421.30 | 487.59 |
B | 7/0.52 | 14.9 | 15.8 | 446.15 | 517.63 | |
R | 30/0.25 | 15.3 | 16.2 | 458.65 | 532.16 | |
16×2.5 | A | 1/1.78 | 16.3 | 17.2 | 623.53 | 702.12 |
B | 7/0.68 | 17.7 | 19.2 | 668.80 | 782.07 | |
R | 49/0.25 | 18.6 | 19.6 | 706.90 | 800.03 |
